INTEGRATED VESSEL OF RSD67_RDB67-RDB67 PROJECTS
11148 DWT total dry-cargo integrated vessel for Dnipro river and north-western part of the Black Sea
Purpose - carrying of the general and bulk cargoes, including steel, grain, fertilizer, coal, coke, ore, building materials, large-dimension cargoes, TEU and FEU containers of international standard in holds, and dangerous cargoes that don't require of power ventilation and intended for operation in tug-barge combination.
Characteristics of vessels see RSD67 and RDB67
| # | Name | Value |
|---|---|---|
| 1. | Main dimensions | |
| Length overall (about), m | 256.50 | |
| Breadth overall (about), m | 17.20 | |
| Breadth, m | 17.0 | |
| 2. | Design Draught on DWL, m | 3.20 |
| 3. | Deadweight at draught d = 3.20 / 3.40 / 3.60 m in river (about), t |
9450 / 10298 / 11148 |
| 4. | Cargo holds capacity (about), m³ | 16309 |
| 5. | Shipping Register of Ukraine class of ship-pusher | KM  Ice20 B-R4-RS 2.0 AUT1-C NAV-1 |
| 6. | Shipping Register of Ukraine class of barge | K B1 |
| 7. | ME power, kW | 2 x 1200 |
| 8. | Crew / berth, pers | 9 / 12 |
