PROJECT PV16M

River passenger vessel for interregional passenger transportation

Main Image
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5 Thumbnail 6

Purpose - passenger transportation by interregional lines.

# Name Value
1. Main dimension
Length overall, m 39.60
Length on DWL, m 38.22
Breadth overall, m 10.20
Breadth, m 10.0
Depth, m 4.20
L x B x H 39.60 x 10.20 x 4.20 = 1 696
2. Draught on DWL, m 2.40
3. Deadweight on DWL draught (in river), t 364
4. Passenger capacity, pers. 100
5. Cargo hold capacity, m³ 102
6. Endurance, days
by fuel stores 5
by fresh water stores, oily bilge water, wastes 2
7. RRR class ° O 2.0 (ice 20) A
8. ME power, kW 2 x 479
9. Rudder and propellers complex 2 x FPP +
2 hanging balanced rudders
10. Auxiliary engines:
diesel-generators, kW 2 x 86
emergency diesel-generator, kW 1 x 28
11. Crew, pers. 5
12. Speed (at 85% MCR), km/h 20
