PROJECT PV16

River passenger vessel for local lines with possibility of opertion in open pack ice thickness 40 cm
of passengers capacity 250 persons

Main Image
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5

Purpose - сarriage of passengers and cargo on inland domestic lines, including in open pack ice thickness 40 cm..

# Name Value
1. Main dimension
Length overall, m 39.60
Length on DWL, m 38.22
Breadth overall, m 10.40
Length overall (hull), m 10.0
Depth, m 4.20
L x B x H 39.60 x 10.40 x 4.20 = 1 730
Height from BL to non-removable parts (not more than), m 13.20
2. Draught on DWL, m 2.40
3. Deadweight at draught by DWL, t 376
4. Endurance, days
by fuel stores 5
by fresh water stores, sewages, oily waters and garbage containers capacities 2
5. Passenger capacity, pers. 250
6. Cargo hold capacity, m³ 100
7. RRR class ° P 1.2 (ice 40) A
8. ME power, kW 2 x 479
9. Rudder and propeller complex 2 x CFP +
2 spade balanced rudders
10. Auxiliary engines:
diesel-generators, kW 2 x 130
emergency diesel-generator, kW 1 x 28
11. Crew, pers. 3
12. Speed, knots 10.8
