PROJECT PV03
Pleasure vessel
Purpose - carrying of VIP passengers.
|
# |
Name |
Value |
1. |
Main dimension |
Length overall, m |
42.32 |
Length between PP, m |
30.88 |
Breadth, m |
5.30 |
Depth, m |
3.10 |
L x B x H |
42.32 x 5.30 x 3.10 = 695 |
Air draft to an upper edge of non-removable parts at draught d = 2.57 m (not greater than), m |
16.50 |
2. |
Draught, m |
2.57 |
3. |
Endurance, days |
5 |
4. |
Range, nautical miles |
1200 |
5. |
Passenger capacity, pers. |
10 |
6. |
Shipping Register of Ukraine class |
KM II A3 pleasure boat |
7. |
ME power, kW |
2 x 256 |
8. |
Auxiliary diesel-generators, kW |
2 x 80 |
9. |
Crew, pers. |
6 |
10. |
Speed at draft d = 2.57 m at MCR of ME (not less than), knots |
10.0 |
|
|
|
|
