PROJECT RST41
3335 DWT dry cargo open-deck ship / oil-chemical tanker type 2








Purpose - self-propelled combined (dry cargo / oil-chemical tanker type 2) open-deck vessel, which is intended for carriage of the crushed stone and other general and bulk cargoes, which can be wet; TEU and FEU containers of international standard, steel, bulldozers and cars, timber, large-dimension and heavy-weight cargoes, also oil and oil products without restriction of the flash point, chemical cargo and vegetable oil. Simultaneous carriage of liquid cargo and dry cargoes on open deck is not allowed.
# | Name | Value |
---|---|---|
1. | Main dimension | |
Length overall, m | 109.90 | |
Length by CWL, m | 109.47 | |
Breadth, m | 17.60 | |
Depth, m | 5.50 | |
2. | Draft, m | 3.00 |
3. | Deadweight at draft 3.00 m, t | 3335 |
4. | Endurance by stores, days | 20 |
5. | Operational range, nm | 4500 |
6. | Height of cargo bay border, m | 2.00 |
7. | Volume of cargo space, m³/h | 1810 |
8. | Cargo and slop tanks’ capacity, m³ | 4574 |
9. | ME power, кW | 2 x 1100 |
10. | Bow thruster, kW | 120 |
11. | Auxiliary diesel-generators, kW | 3x316 |
12. | Emergency diesel-generator, kW | 100 | 13. | Crew / berths, pers. | 10 / 16 |
14. | Speed, knots (at draft 3.00 m and 85% MCR) | 10.0 |
15. | RINA class | C ![]() ![]() Oil tanker-chemical tanker (IMO 2)-ESP Deck cargo ship Unrestricted navigation AUT-UMS INWATERSURVEY BWM(T) INERTGAS-B NOx-Tier III |
