PROJECT RST22TP

7014 DWT chemical - product tanker IMO2


Purpose - sea and mixed (river-sea) carrying of 53 chemically dangerous cargo with ensuring temperature of carrying cargo up to 50°C. Providing simultaneous carriage six sorts of cargo.


# Name Value
1. Main dimensions
Length overall, m 139.95
Length, m 134.50
Breadth overall, m 16.83
Breadth, m 16.60
Depth, m 6.0
Depth of trunk, m 1.0
L x B x H 139.95 x 16.83 x 6.0 = 14 132
Air draft from WL at draught d = 3.0 m, m 14.20
2. Draught (at sea / in river), m 4.60 / 3.60
3. Ballast draft, m 3.12
4. Deadweight (at sea / river), t 7014 / 4617
5. Endurance (at sea / river), days 20 / 10
6. Range, nautical miles 4000
7. Number of tanks (cargo / slop) 8 (6 / 2)
8. Tanks capacity (cargo / slop), m³ 7833 / 256
9. Ballast tanks capacity, m³ 3606
10. Number of manifolds / sorts of cargo 6 manifolds / 6 sorts
11. Cargo pumps: 3 x 300 m³/h +
3 x 200 m³/h
12. Tank wash system
and cleaning of washing liquid
slop tank's pump output 80 m³/h
13. RS class KM Ice1 R2 AUT1-ICS VCS OMBO BWM
(T) oil/chemical tanker type 2 (ESP)
14. ME power, kW 2 x 1200
15. Rudder and propeller complex 2 x Rudderpropellers
16. Bow thruster, kW 230
17. Auxiliary engines:
diesel-generators, kW 3 x 220
emergency diesel-generator, kW 1 x 100
18. Boilers:
thermal, kW 1 x 1750
exhaust gas, kW 2 x 250
19. Crew / berth, pers. 12 / 15
20. Speed, knots 10.5
