PROJECT RST12
7183 / 5632 DWT product - tanker




Purpose - sea and mixed (river-sea) carrying of crude oil and petroleum products with density up to 1.015 t/m³, including gasoline without restrictions for flash-point, with ensuring temperature of carrying cargo up to 50°C. Simultaneous carriage 2 sorts of cargo is provided.
# | Name | Value |
---|---|---|
1. | Main dimensions | |
Length overall, m | 141.0 | |
Length between PP, m | 137.26 | |
Breadth overall | 16.98 | |
Breadth scantlings | 16.90 | |
Depth, m | 5.50 | |
L x B x H | 141.0 x 16.98 x 5.50 = 13 168 | |
2. | Draught (at sea (at SWL) / in river), m | 4.17 / 3.60 |
3. | Deadweight (at sea (at SWL) / in river), t | 7183 / 5632 |
4. | Endurance (at sea / in river), days | 20 / 12 |
5. | Number of tanks (cargo / slop) | 8 (6 / 2) |
6. | Cargo tanks capacity (including slop tanks), m³ |
8075 |
7. | Number of manifolds / sorts of cargo | 2 manifolds / 2 sorts |
8. | Cargo pumps, m³/h | 6 x 200 |
9. | Cargo heating | coils |
10. | Tank wash system and cleaning of washing liquid |
slop tank's pump output 80 m³/h |
11. | RS class | KM ![]() ECO-S OMBO Oil tanker (ESP) |
12. | ME power, kW | 2 x 1200 |
13. | Rudder and propeller complex | 2 x Rudderpropellers |
14. | Bow thruster, kW | 230 |
15. | Auxiliary engines: | |
diesel-generators, kW | 2 x 350 | |
emergency / harbor diesel-generator, kW | 1 x 150 | |
16. | Thermal boilers, t/h | 2 x 2.0 |
17. | Crew / berth, pers. | 12 / 14 + pilot |
18. | Speed (at draft d = 4.20 m and 100% MCR), knots | 10.2 |
