PROJECT ROB20
6000 t cargo capacity non-self-propelled oil tanker O 2.0 navigation area
Purpose - carrying of the petroleum products with flash-point 61°C and above, main type of cargo - fuel oil. Design range of cargo density - 0.92...1.015 t/m³.
| # | Name | Value |
|---|---|---|
| 1. | Main dimensions | |
| Length overall, m | 118.79 | |
| Length between PP, m | 117.90 | |
| Breadth overall, m | 22.80 | |
| Breadth, m | 22.60 | |
| Depth scantling, m | 4.0 | |
| Depth to the main deck, m | 3.0 | |
| Depth of trunk, m | 1.0 | |
| L x B x H, m | 118.79 x 22.80 x 4.0 = 10 831 | |
| 2. | Draught on DWL, m | 2.75 |
| 3. | Deadweight in river at DWL draught, t | 6000 |
| 4. | Number of tanks (cargo / slop) | 12 / 2 |
| 5. | Tanks capacity (cargo / slop), m³ | 6870 (6530 / 340) |
| 6. | RRR class |  O 2.0 |
| 7. | Towing attachment | vertical drag-bar for automatic drag lock O-200 type |
