PROJECT 1557/550A MODERNIZATION

6654 DWT product - tanker

Main Image
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5 Thumbnail 6 Thumbnail 7

Purpose - sea and mixed (river-sea) carring petroleum products I, II, III, IV types.


# Name Value
1. Main dimension
Length overall, m 132.60
Length, m 128.60
Breadth overall, m 16.90
Breadth, m 16.50
Depth, m 5.50
Depth of trunk 1.50
L x B x H 132.60 x 16.90 x 5.50 = 12 325
2. Draught (at sea / in river), m 4.46 / 3.60
3. Deadweight (at sea / in river), t 6654 / 4780
4. Endurance, days 7
5. Cargo carrying capacity (at sea / in river), t 6473 / 4600
6. Number of cargo tanks 8
7. Cagro tanks capacity, m³ 7055
8. Number of manifolds 3
9. Cargo pumps, m³/h 2 x 450
10. Stripping pump, m³/h 1 x 78
11. Ballast tanks capacity, m³ 3119
12. RS class KM IISP oil carrier (ESP)
13. ME power, kW 2 x 736
14. Auxiliary engines:
diesel-generators, kW 2 x 100
emergency diesel-generator, kW 1 x 50
15. Crew, pers. 22
16. Speed, knots 10.0
