PROJECT 003RST06
2972 DWT product - tanker
(modernization of project R77 tanker)








							Purpose - sea and mixed (river-sea) carrying of petroleum products, including benzine without restrictions for flash-point. Providing simultaneous carriage three sorts of cargo.
| # | Name | Value |
|---|---|---|
| 1. | Main dimensions | |
| Length overall, m | 108.50 | |
| Length, m | 105.98 | |
| Breadth overall, m | 15.22 | |
| Breadth, m | 14.80 | |
| Depth, m | 4.40 | |
| Depth of trunk, m | 1.36 | |
| L x B x H | 108.50 x 15.22 x 4.40 = 7 266 | |
| Air draft from WL at draught d = 1.70 m, m | 12.90 | |
| 2. | Draught (at sea / in river), m | 3.09 / 3.50 |
| 3. | Ballast draft, m | 2.24 |
| 4. | Deadweight (at sea / in river), t | 2972 / 3555 |
| 5. | Endurance, days | 15 |
| 6. | Range, nautical miles | 3600 |
| 7. | Cargo carrying capacity (at sea / in river), t | 2867 / 3450 |
| 8. | Number of cargo tanks | 10 |
| 9. | Cargo tanks capacity, m³ | 3859 |
| 10. | Number of manifolds / sorts of cargo | 4 manifolds / 3 sorts |
| 11. | Cargo pumps: | 2 x 148 m³/h + 2 x 45 m³/h  |

| 12. | Tank wash system and cleaning of washing liquid  |
	stripping pump output 55 m³/h |
| 13. | Ballast tank capacity, m³ | 1685 |
| 14. | RRR class |   M-SP 3.5 (ice 30) |

| 15. | ME power, kW | 2 x 515 |
| 16. | Auxiliary engines: | |
| diesel-generators, kW | 2 x 100 | |
| emergency diesel-generator, kW | 1 x 50 | |
| 17. | Crew, pers. | 11 |
| 18. | Speed, knots | 10 |
 M-SP 3.5 (ice 30)
