PROJECT ST-192
Big refrigerating trawler - processor







Purpose - catching pelagic and near-bottom pelagic type fish, also manufactory of frozen production during the voyage; with full cycle of take processing onboard vessel directly.
# | Name | Value |
---|---|---|
1. | Main dimension | |
Length overall (about), m | 108.20 | |
Breadth, m | 21.00 | |
Depth to the main deck, m | 8.35 | |
Depth up to trawl deck, m | 11.55 | |
L x B x H | 108.20 x 21.00 x 8.35 = 18 973 | |
2. | Maximum stern draft, m | 8.35 |
3. | Deadweight, including all fishing gear, t | 5700 |
4. | Endurance by fuel and provision stores, days | 45 |
5. | Processing equipment capacity, t/day: | |
fish processing system | 260 | |
fish meal plant | 250 | |
surimi production | 80 | |
6. | Refrigerating holds, m³: | |
main refrigerating hold | 4000 | |
fish meal hold / bow refrigerating hold | 400 | |
fish meal hold / refrigerating hold in FD | 600 | |
storage of carrying carton hold, fishmeal, other products / frigerating hold |
500 | |
7. | Fish oil tanks, m³ | 100 |
8. | Deck cargo cranes (lifting capacity x boom): | |
aft | 8 t x 8 m | |
middle | 8 t x 17 m | |
9. | Fore / aft gantries with cargo double derricks, t | 5 / 5 |
10. | RS class | KM ![]() REF BWM (T) Fishing vessel |
11. | ME power, kW | 1 x 8120 |
12. | Rudder and propeller complex | CPP in non rotate nozzle + ruder with flap |
13. | Bow thruster, kW | 1 x 950 |
14. | Auxiliary engines: | |
diesel-generators, kW | 1 x 1880 1 x 1460 |
|
shaft generator, kW | 4126 | |
emergency diesel-generator, kW | 1 x 240 | |
15. | Duty motorboat | 2 x 6 pers. |
16. | Inflatable liferafts | 8 x 35 pers. + 3 x 25 pers. |
17. | Crew / factory staff, pers. | 40 / 99 |
18. | Speed, knots | 15 |
