PROJECT CNF02
Railway ferry for 50 railway cars "Skif" type
(lines: port Kavkaz - ports Samsun, Poti, Varna)
Purpose - carrying of the railway trains.
| # | Name | Value |
|---|---|---|
| 1. | Main dimension | |
| Length overall, m | 139.52 | |
| Breadth overall, m | 22.0 | |
| Depth, m | 6.75 | |
| L x B x H | 139.52 x 22.0 x 6.75 = 2 072 | |
| Air draft from BL, m | 31.14 | |
| 2. | Draught at SWL, m | 3.50 |
| 3. | Ballast draft, m | 2.37 |
| 4. | Deadweight, t | 5420 |
| 5. | Endurance, days | 15 |
| 6. | Number of cargo decks | 1 |
| 7. | Loading capacity for railway cars: | |
| cisterns of T-1 gauge with length between autoreplacers 12020 mm (four-axled), units |
50 | |
| 8. | Ballast tanks capacity, m³ | 2457 |
| 9. | RS class | KM  LU2  IISP (roll-on roll-off) |
| 10. | ME power, kW | 2 x 662 |
| 11. | Crew / passengers, pers. | 16 / 8 |
| 12. | Speed, knots | 9.0 |
