PROJECT RSD62
5640 / 5304 DWT dry-cargo vessel river and mixed (river-sea) navigation








Purpose - sea and mixed (river-sea) carriage of general, bulk, timber and large-dimension cargoes, containers of international standard, dangerous cargoes of classes 1.4S, 2, 3, 4, 5, 6.1, 8, 9 and Annex B of BC Code, coal.
# | Name | Value |
---|---|---|
1. | Main dimensions | |
Length overall, m | 141.0 | |
Length between PP, m | 140.82 | |
Breadth overall, m | 16.98 | |
Breadth, m | 16.90 | |
Depth, m | 6.30 | |
L x B x H | 141.0 x 16.98 x 6.30 = 15 012 | |
2. | Draught on SWL, m | 3.56 |
3. | Ballast draft (mean), m | 3.0 |
4. | Deadweight at sea at SWL draught, t | 5640 |
5. | Deadweight in river at draught (d = 3.50 m) / (d = 2.50 m), t | 5304 / 2992 |
6. | Endurace, days | 20 |
7. | Number of cargo holds | 4 |
8. | Cargo holds capacity, m³ | 8404 |
9. | Container capacity (holds / deck): | |
TEU | 225 (150 / 75) | |
FEU | 105 (70 / 35) | |
10. | Ballast tanks capacity, m³ | 4706 |
11. | RRR class | ![]() |
12. | Maximum continuous rating of ME, kW | 2 x 1200 |
13. | Rudder and propeller complex | 2 x Rudderpropellers |
14. | Bow thruster, kW | 230 |
15. | Auxiliary engines: | |
diesel-generators, kW | 3 x 160 | |
emergency diesel-generator, kW | 1 x 60 | |
16. | Crew / berths, pers. | 9 / 14 |
17. | Speed (not less than), knots | 10 |
