PROJECT RSD59

8144 / 5320 DWT Multipurpose river-sea dry-cargo vessel


Purpose - sea and mixed (river-sea) carrying of the general and bulk cargoes (including grain), packaged lumber, timber, scrap-metal, bunched and rolled steel, large-dimension and heavy-weight cargoes, coil, hazardous cargoes of classes 1, 2, 3, 4, 5, 6.1, 8, 9 in accordance with IMDG Code and category "B" cargoes from IMSBC Code.

Nominations:
RINA - Royal Institution of Naval Architects


Laying of the keel Laid down Delivery Years of construction
5 8 49 2017-


# Name Value
1. Main dimension
Length overall, m 140.88
Length between PP, m 137.08
Breadth overall, m 16.98
Breadth scantlings, m 16.90
Depth, m 6.0
L x B x H, m 140.88 x 16.98 x 6.0 = 14 352
2. Draught (at sea / in river), m 4.706 / 3.60
3. Deadweight (at sea / in river) (about), t 8144 / 5320
4. Endurance (at sea / in river), days 20 / 12
5. Number of cargo holds 2
6. Cargo holds capacity, m³ 11400
7. Container capacity (holds / deck), TEU 248 (192 / 56)
8. RS class KM Ice2(hull; power) R2 AUT1-ICS BWM(T)
CONT (deck, cargo holds Nos.1,2) DG (bulk, pack)
9. ME power, kW 2 x 1200
10. Rudder and propeller complex 2 x Rudderpropellers
11. Bow thruster, kW 1 x 230
12. Auxiliary engines:
diesel-generators, kW 2 x 332
emergency diesel-generator, kW 1 x 90
13. Crew / berth, pers. 11 / 14
14. Speed (at draft d = 4.5 m and 100% MCR), knots 10.2 ±0.2
