PROJECT RSD09

6208 DWT multipurpose dry-cargo vessel of "Danube mouthing six-thousander" class


Purpose - sea and mixed (river-sea) carrying of the general and bulk cargoes, including steel, grain, timber, coal, large-dimension and heavy-weight cargoes, hazardous cargoes of classes 1.4S, 2, 3, 4, 5, 6.1, 8, 9.

# Name Value
1. Main dimensions
Length overall, m 109.12
Length scantlings, m 105.12
Breadth overall, m 16.52
Breadth scantlings, m 16.50
Depth, m 6.50
L x B x H 109.12 x 16.52 x 6.50 = 11 717
2. Draught on SWL, m 5.50
3. Deadweight at sea at SWL draught, t 6208
4. Deadweight at sea at draught d = 4.50 m, t 4575
5. Endurance, days 25
6. Number of cargo holds 3
7. Cargo holds capacity, m³ 8251
8. Ballast tanks capacity, m³ 2497
9. Stowage factor, m³/t:
at draft d = 5.50 m (at sea) 1.44
at draft d = 4.50 m (at sea) 2.01
10. Shipping Register of Ukraine class KM LP1 I A1
11. ME power, kW 1 x 2760
12. Rudder and propeller complex 1 CPP + 1 rudder
13. Bow thruster, kW 250
14. Auxiliary engines:
diesel-generators, kW 2 x 292
shaft generator, kW 1 x 292
emergency diesel-generator, kW 1 x 133
15. Crew / berth, pers. 14 / 15
16. Speed (at draft d = 5.50 m and 85% MCR), knots 11.5 ±0.3
