PROJECT RDB20
6000 DWT shallow draught non-self-propelled river multipurpose vessel









							Purpose - carrying bulk cargoes with the possibility of loading and unloading using a crane with a grab.
| # | Name | Value |
|---|---|---|
| 1. | Main dimensions | |
| Length overall with hull appurtenances, m | 118.94 | |
| Length by DWL, m | 117.83 | |
| Breadth overall, m | 22.80 | |
| Breadth scantlings, m | 22.60 | |
| Depth scantlings, m | 4.0 | |
| L x B x H | 118.94 x 22.80 x 2.60 = 7 044 | |
| 2. | Draught (γ = 1.0 t/m³), m | 2.85 |
| 3. | Deadweight at draught d = 2.85 m, t | 6000 |
| 4. | Number of cargo holds | 6 |
| 5. | Cargo holds capacity, m³ | 9130 |
| 6. | Hatch covers | splashproof removable type |
| 7. | RRR class |   O 2.0 |

 O 2.0
