PROJECT DCB23

6222 DWT non-self-propelled dry-cargo vessel


Purpose - carrying of the general and bulk cargoes including steel, scrap, grain, timber, logs and carving woods, building materials, paper.

# Name Value
1. Main dimension
Length overall, m 99.98
Length, m 99.60
Breadth overall, m 16.71
Breadth, m 16.50
Depth at midship, m 8.0
L x B x H 99.98 x 16.71 x 8.0 = 13 365
Air draft from WL at draught d = 3.30  m, m 13.90
2. Draught on DWL, m 5.0
3. Deadweight at DWL draught, t 6222
4. Number of cargo holds 4
5. Cargo holds capacity, m³ 9766
6. Hatch covers ponton type
7. Cargo crane gantry crane for hatch covers
8. RS class KE R2
9. Bow thruster, kW 120
10. Diesel-generators 1 x 168 kW +
1 x 52 kW
11. Watch place, pers. 2
