PROJECT 326.1 MODERNIZATION
2162 / 1827 DWT dry-cargo vessel








Purpose - sea and mixed (river-sea) carrying of the general and bulk cargoes, including containers of internationall standard in holds and on the container deck, grain and timber.
# | Name | Value |
---|---|---|
1. | Main dimension | |
Length overall, m | 82.81 | |
Length between PP, m | 78.10 | |
Breadth overall, m | 11.94 | |
Breadth scantlings, m | 11.60 | |
Depth, m | 6.20 | |
L x B x H | 82.81 x 11.94 x 6.20 = 6 130 | |
2. | Draught (at sea / in river), m | 3.90 / 3.60 |
3. | Deadweight (at sea / in river), t | 2162 / 1827 |
4. | Endurance, days | 20 |
5. | Number of cargo holds | 2 |
6. | Cargo holds capacity, m³ | 1943 |
7. | Container capacity (holds / deck), TEU | 70 (34 / 36) |
8. | Ballast tanks capacity, m³ | 998 |
9. | Stowage factor, m³/t: | |
at draft d = 3.90 m (at sea) | 0.96 | |
at draft d = 3.60 m (in river) | 1.13 | |
10. | RS class | KM ![]() |
11. | ME power, kW | 2 x 441 |
12. | Rudder and propeller complex | 2 FPP + 4 rudders |
13. | Auxiliary engines: | |
diesel-generators, kW | 2 x 100 | |
emergency diesel-generator, kW | 1 x 50 | |
14. | Crew, pers. | 12 |
15. | Speed, knots | 10.0 |
