PROJECT 19620M MODERNIZATION

2858 / 2279 DWT dry-cargo vessel


Purpose - sea and mixed (river-sea) carrying of the general and bulk cargoes, including containers of internationall standard, grain, timber.

# Name Value
1. Main dimension
Length overall, m 88.90
Length, m 83.60
Breadth overall, m 12.20
Breadth, m 12.0
Depth, m 5.96
L x B x H 88.90 x 12.20 x 5.96 = 6 464
2. Draught (at sea / in river), m 4.10 / 3.60
3. Ballast draft, m 1.92
4. Deadweight (at sea / in river), t 2858 / 2279
5. Endurance, days 15
6. Number of cargo holds 3
7. Cargo holds dimensions (l x b x h), m 12.10 x 6.20-9.0 x 6.0
21.45 x 9.0 x 6.0
19.80 x 9.0 x 6.0
8. Cargo holds capacity, m³ 2827
9. Container capacity (holds / deck), TEU 63 (42 / 21)
10. Ballast tanks capacity, m³ 641
11. RS class KM L4 IISP (L4 when d ≤ 3.0 m)
12. ME power, kW 2 x 515
13. Auxiliary engines:
diesel-generators 2 x 100 kW +
1 x 50 kW
emergency diesel-generator, kW 1 x 50
14. Crew / berth , pers. 12 / 12
15. Speed, knots 9.5
