PROJECT 191 MODERNIZATION

2800 / 2210 DWT dry-cargo vessel




Purpose - sea and mixed (river-sea) carrying of the general and bulk cargoes, including containers of international standard, grain and timber.




# Name Value
1. Main dimension
Length overall, m 88.70
Length between PP, m 82.95
Breadth overall, m 12.20
Breadth scantlings, m 12.0
Depth, m 5.80
L x B x H 88.70 x 12.20 x 5.80 = 6 276
2. Draught (at sea / in river), m 4.10 / 3.60
3. Deadweight (at sea / in river), t 2800 / 2210
4. Endurance, days 20
5. Number of cargo holds 1
6. Cargo hold capacity, m³ 2360
7. Container capacity (hold / deck), TEU 72 (36 / 36)
8. Ballast tanks capacity, m³ 775
9. Stowage factor, m³/t:
at draft d = 4.10 m (at sea) 0.88
at draft d = 3.60 m (in river) 1.12
10. RS class KM L4 IISP (L4 at d ≤ 3.0 m)
11. ME powers, kW 2 x 460
12. Rudder and propeller complex 2 FPP + 4 rudders
13. Auxiliary engines:
diesel-generators, kW 3 x 100
emergency diesel-generator, kW 1 x 50
14. Crew, pers. 12
15. Speed, knots 10.0
